Yedoo Numbers
Four
Cool design, isn't it? But do not be misled, this scooter is built to manage everything. Number four will give you certainty as well as perhaps a drop of adrenalin, without any unnecessary embellishments. Reliable components and the entire technological superiority the twenty-years’ tradition of the Yedoo brand provide the nearly unbreakable machine with confident speed and agility in the city jungle – and 4x4 features, as soon as you get clear off the suburbs.
Technical data
-
Max. 150 kg
-
Min. 150 cm
-
20"/16"
-
10,2 kg
-
12 +
-
Technical details
-
Product number12208
-
Loading limit150 kg / 330 lb
-
Min. height of rider150 cm / 59 in
-
Weight (with/without kickstand)10,5 / 10,2 kg // 23.1 / 22.5 lb
-
Box size105 x 64 x 18 cm (41.3 x 25.2 x 7.1 in)
-
Box weight12,5 kg / 27.6 lb
-
FrameYEDOO Hi-ten steel
-
ForkYEDOO Hi-ten steel
-
StemZOOM steel
-
HandlebarYEDOO Cross Hi-ten steel
-
GripsErgonomic (with anti-rotation lock)
-
HeadsetFP steel 1 1/8" threaded
-
Brake levers2x SPARKLE alloy
-
Brakes (front/rear)"V" TEKTRO alloy /"V" TEKTRO alloy
-
Wheels20" / 16"
-
RimsHJC alloy
-
HubsNOVATEC alloy
-
Hub width (front/rear)74 / 74 mm // 2.9 / 2.9 in
-
Preparation for using flat screws (front/ rear)No / No
-
BearingsIndustrial
-
Quick-release levers (front/rear)Yes / Yes
-
Tyres (front/rear)INNOVA 20x1,75 / 16x1,75
-
Max. inflation (front/rear)4,6 bar / 4,6 bar
-
Preparation for bottle holder2x
-
KickstandYedoo central, integrated
-
Reflective elementsNo
-
Dimensions
-
-
[1] Length145 cm / 57.1 in
-
[2] Footboard40 cm / 15.7 in
-
[3] Handlebar height92 - 100 cm / 36.2 - 39.4 in
-
[4] Width of handlebars64 cm / 25.2 in
-
[5] Ride height (higher/lower position)*4,5 / 6,5 cm // 1.8 / 2.6 in
-
[6] Distance between footboard and ground (higher/lower position)*8 / 10 cm // 3.2 / 3.9 in
-
[7] Room for rider59 cm / 23.2 in
-
*Tolerance +-0.2 cm
-
Documents, standards and certificates
-
Manual
-
NormsČSN EN 14619
ČSN EN 14619
The regulation determines safety and functional requirements for wheel sport equipment particularly scooters aimed for users between 35kg and 100kg. The regulation examines riding properties, strength of construction, safety fixing components, shelf life and correct functionality of individual components such as brakes, bearings, rims, cases, pedals, etc. The regulation also introduces guidelines for preparation of user´s manuals, installation and treatment of these products.
-
Testing authoritySZÚ, s. p.
-
-
We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More
-
Yedoo frames are protected by registered EU industrial designs. The Yedoo brand, along with the trade names of each model, are trademark protected.
-
Change of technical parameters and components reserved.
Manual_Yedoo_Adult_scooters_2020_2016_1616_web.pdf
