Yedoo Steel
S1616
A jewel that will pull you outdoors regardless of the weather. It fits into every opening in traffic and provides even smaller riders with due comfort and stability. Resistant but irresistible.
Yedoo Steel
S2016





















Availability:
Yedoo Steel
Around the World 2620
Technical data
-
Max. 150 kg
-
Min. 140 cm
-
16"/16"
-
8,4 kg
-
12 +
-
Technical details
-
Product number12406
-
Loading limit150 kg / 330 lb
-
Min. height of rider140 cm / 55 in
-
Weight (with/without kickstand)8,4 kg / 18.5 lb
-
Box size101 x 15,5 x 55 cm (39.8 - 6.1 x 21.7 in)
-
Box weight10,5 kg / 23.1 lb
-
FrameYEDOO Hi-ten steel
-
ForkYEDOO Hi-ten steel
-
StemZOOM alloy/steel
-
HandlebarYEDOO BMX alloy
-
GripsErgonomic (with anti-rotation lock)
-
Bar endsOptional
-
HeadsetNECO alloy 1 1/8" threaded
-
Brake leversTEKTRO ML 520 alloy
-
Brakes (front/rear)"V" TEKTRO alloy /"V" TEKTRO alloy
-
Wheels16" / 16"
-
RimsHJC alloy double wall + CNC milled braking surface
-
HubsNOVATEC alloy
-
Hub width (front/rear)74 / 74 mm // 2.9 / 2.9 in
-
Preparation for using flat screws (front/ rear)Yes / Yes
-
BearingsIndustrial
-
Quick-release levers (front/rear)Yes / Yes
-
Tyres (front/rear)KENDA
-
Max. inflation (front/rear)4,6 bar / 4,6 bar
-
Preparation for bottle holder1x
-
KickstandOptional
-
Reflective elementsNo
-
Dimensions
-
-
[1] Length138 cm / 54.3 in
-
[2] Footboard40 cm / 15.7 in
-
[3] Handlebar height90 - 100 cm / 35.4 - 39.4 in
-
[4] Width of handlebars64 cm / 25.2 in
-
[5] Ride height (higher/lower position)*4,0 / 6,0 cm // 1.6 / 2.4 in
-
[6] Distance between footboard and ground (higher/lower position)*6,8 / 8,8 cm // 2.7 - 3.5 in
-
[7] Room for rider60 cm / 23.6 in
-
*Tolerance +-0.2 cm
-
Documents, standards and certificates
-
Manual
-
NormsČSN EN 14619
ČSN EN 14619
The regulation determines safety and functional requirements for wheel sport equipment particularly scooters aimed for users between 35kg and 100kg. The regulation examines riding properties, strength of construction, safety fixing components, shelf life and correct functionality of individual components such as brakes, bearings, rims, cases, pedals, etc. The regulation also introduces guidelines for preparation of user´s manuals, installation and treatment of these products.
-
Testing authoritySZÚ, s. p.
-
-
We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More
-
Yedoo frames are protected by registered EU industrial designs. The Yedoo brand, along with the trade names of each model, are trademark protected.
-
Change of technical parameters and components reserved.
