Yedoo Kids
Wzoom Emoji
Smileys were used by monks in the Žďár nad Sázavou monastery in the 18th century already to express emotions in their correspondence – and nowadays children test the limits of acceptability with them (💩💩💩😛!) as well as gravity. Ideal for a 😈 for the first independent trips, with a group of friends to the park or to ⚽️. Wzoom is not a fully “big” scooter yet, but the wheels match some adult models already – and it definitely feels adult 😉. It is fast enough for it ⚡️⚡️⚡️ and as strong as the road: it can carry a hundred kilos! 👍🏻 Due to the frame construction and selected components, it maintains childlike lightness and agility, but it will endure a good few kilometres in one go. Slower rivals will of course turn 🤢 with envy! So who is the hindrance here? 😛
Technical data
-
Max. 100 kg
-
Min. 120 cm
-
16"/12"
-
7,7 kg
-
6 +
-
Technical details
-
Attention! Components may vary depending on current availability. More
-
Age6+
-
Product number12315
-
Loading limit100 kg / 220 lb
-
Min. height of rider120 cm / 47 in
-
Weight (with/without kickstand)7,5 / 7,3 kg // 16.5 / 16.1 lb
-
Box size90,5 x 14,5 x 54,5 cm (35.6 x 5.7 x 21.5 in)
-
Box weight9,2 kg / 20.3 in
-
FrameYEDOO Hi-ten steel
-
ForkYEDOO Hi-ten steel
-
StemYEDOO Hi-ten steel 22,2/25,4
-
HandlebarYEDOO Hi-ten steel
-
GripsMolded handles with wider endings, Yedoo
-
HeadsetNECO steel 1" threaded
-
Brake levers2x TEKTRO JL510-RS alloy
-
Brakes (front/rear)2x "V" TEKTRO alloy
-
Wheels16" / 12"
-
RimsHJC alloy
-
HubsJOYTECH steel
-
Hub width (front/rear)74 / 74 mm // 2.9 / 2.9 in
-
Preparation for using flat screws (front/ rear)No / No
-
BearingsConical
-
Quick-release levers (front/rear)No / No
-
Tyres (front/rear)KENDA / INNOVA / 16x2,25 / 12x2,25
-
Max. inflation (front/rear)4,5 bar / 5,5 bar
-
Preparation for bottle holder1x
-
KickstandYedoo central, integrated
-
Reflective elementsOn the handlebar cover and tyres (only applies to Kenda tyres)
-
Based onYedoo Wzoom
-
Dimensions
-
-
[1] Length123 cm / 48.4 in
-
[2] Footboard34 cm / 13.4 in
-
[3] Handlebar height81 - 90 cm / 31.9 - 35.4 in
-
[4] Width of handlebars56 cm / 22 in
-
[5] Ride height (higher/lower position)*4,2 / 5,8 cm // 1.7 / 2.3 in
-
[6] Distance between footboard and ground (higher/lower position)*7,3 / 8,9 cm // 2.9 / 3.5 in
-
[7] Room for rider50 cm / 19.7 in
-
*Tolerance +-0.2 cm
-
Documents, standards and certificates
-
Manual
-
NormsČSN EN 14619
ČSN EN 14619
The regulation determines safety and functional requirements for wheel sport equipment particularly scooters aimed for users between 35kg and 100kg. The regulation examines riding properties, strength of construction, safety fixing components, shelf life and correct functionality of individual components such as brakes, bearings, rims, cases, pedals, etc. The regulation also introduces guidelines for preparation of user´s manuals, installation and treatment of these products.
-
Testing authoritySZÚ, s. p.
-
-
We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More
-
Yedoo frames are protected by registered EU industrial designs. The Yedoo brand, along with the trade names of each model, are trademark protected.
-
Change of technical parameters and components reserved.
Manual_Yedoo_Kids_scooters_web.pdf
Technical and construction features
Originally designed frame
The unique dual-tube construction has enabled us to make the scooter frame as light as possible and to shorten it so that the scooters would be easy for children to handle, carry and park.
Special reinforcement
The originally designed reinforcement with the shape of the initial increases the strength of the frame and ensures optimum solidity of the scooter.
Adjustable handlebars with reflective cover
The shape and size of the handlebar are adjusted to the age of the riders.
In order to make sure no one overlooks the children on their way to school, we have added reflective print to the handlebar cover.
Widened and reinforced grips in Yedoo design and Tektro brake levers
The grips adjusted for size fit well into kids' hands, the reinforced and widened ends protect the kids' hands when riding and in case of a fall.
The junior brake levers are easy to handle, they are short-reach, operate smoothly and their distance from the handlebar is adjustable.
Prepared for a bottle holder
In order for the young travellers not to run out of juice on the way, the scooter is prepared for bottle holder installation.
Yedoo footboard
The spacious footboard provides enough space for a comfortable ride. The anti-slip surface of the deck contributes to a safe ride even in more demanding terrain and weather conditions, such as wet ground, leaves, mud.
Folding stand
The stand, which is fully integrated into the construction of the frame, ensures stable parking of the scooter. Another piece of good news is that when folded, it has only minimum impact on the scooter passing through the terrain.
Tektro Alloy brakes and alloy rim
Quality brakes are the basis of the general safety of the scooter. They are complemented by kids' short-reach brake levers, which are easy to handle and contribute to even greater safety.
Quality aluminium rims, which are light, firm and durable, enhance the safety of the ride.
Dual position rear fork
The dual-position rear fork will enable setting up the ride height of the footboard for road and off-road.
